The products made of colored cement tiles have high density, high strength, good resistance to rain and frost, smooth surface and accurate dimensions. Colored cement tiles are diverse in color, have a long service life, and are cheap to produce. It applies not only to ordinary houses, but also to the waterproof insulation of high-end villas and high-rise buildings. The following small series introduces the construction process of color cement tiles and the applicable range of color cement tiles.
Color cement tile construction process
1, leveling line
Before the construction of the color cement tile, the roof leveling process should be performed first, and then the line should be played to ensure the beautiful appearance of the color cement tile. First determine the entire outline of the roof, and pop up the middle of the ridge in the middle of its roof, dividing the roof into two equal parts. Then, the parallel lines of the eaves are popped up to determine the location of the colored cement tiles on the first floor, and then the horizontal and vertical lines of the eaves are displayed to ensure that the colored cement tiles are laid in a straight line, avoiding the distortion of the colored cement tiles. Affect its overall aesthetics.
2, drain location
The location and width of the drainage ditch shall be determined according to the area of ​​the catchment area and the design slope of the roof. Draw the center line in the middle of the drainage ditch, and in accordance with the relevant requirements, peg two straight along the centerline at intervals. .
3, hanging tiles installed
After the position of the drain is determined, the installation of the battens can be performed. Based on the position of the centerline of the drainage ditch, the best right angle is selected as the upper edge, and the battens are nailed at intervals. The interfaces of the lining bars should be staggered and their upper edges should be on the same straight line.
4, color cement tile installation
After the first layer of colored cement tile is applied on the paving, there will be a phenomenon of dangling, so when it is installed, it should be padded with a tile to ensure that the first layer of color cement tile and the first layer above The colored cement tiles remain on the same plane. After the laying of the first layer of color concrete tile, the color cement tile behind it shall be laid along the elastic line, layer by layer. It should be noted that when the roofing color cement tile is laid, it must be nailed with a steel nail in order to avoid loosening of the tile.
5, laying tiles on the roof
The roof of the ridge is to be installed from the top of the diagonal ridges when laying colored cement tiles, and its installation method is to install from the bottom up. The bottom of the ridge is filled with slurry to fill the floor. When the tiles are tiled, they should be tiled to their right ridge.
6, node processing
Where roof tiles are laid and connected, waterproof treatment should be done to ensure the waterproofness of the roof. The waterproof material at the roof node is generally selected from waterproof mortar, hemp knife, etc., which can ensure the waterproofness of the roof without destroying the overall appearance of the color cement tile.
Color cement tile features
1. It belongs to concrete components, with high strength, good compactness, low water absorption and long service life. Due to the large area of ​​tile, the amount of cover per unit area is much less than that of clay tiles and glazed tiles. Therefore, the weight of the tiles used per unit area is much lighter, and the efficiency of the tiling is also high.
2, it only needs to be maintained at about 40 degrees, without high-temperature roasting, so the deformation is minimal, covered in the roof is flat and beautiful.
3ã€Various types of tile, various production equipment and craftsmanship, color tile color can be arbitrary, not only can be made of a single surface, a variety of color surface superimposition, can also be made of whole body monochrome and whole body mixed camouflage, to the building Designer endless choices.
4. A layer of sealant is sprayed on the surface of the tile to prevent secondary efflorescence on the concrete surface. This kind of sealant generally has anti-mildew and self-cleaning effect, so that the surface of the tile can not be black for a long period of time, and it does not have long moss. The color of iron oxide pigment mixed with cement can remain unchanged for several decades (Note: The color of the paint on the surface of the tile can only be maintained for several years).
5. The production efficiency of color concrete tiles is relatively high. Currently, the world's highest production rate has reached 120 tablets per minute, and it is progressing to 140 tablets per minute.
6. Low energy consumption in the production process and no smoke and dust pollution. Since the main raw material is cement river sand, it does not invade farmland resources.
Application of color cement tile
1, mainly used for multi-storey and low-rise buildings, more suitable for villas.
2. Suitable for waterproof grade II (one to two waterproof and waterproof cushion), Class III (waterproof and waterproof, and waterproof cushion), IV (waterproof, no waterproof cushion) Waterproof roof. The waterproof cushion is laid under the waterproof layer and can also be used as a waterproof layer to protect the roof and prolong the service life of the roof. Waterproof coatings should not be used as a waterproof or waterproof mat.
Editor's summary: The construction process of the color cement tile and the application scope of the color cement tile are introduced here. We hope to help everyone. If you want to know more about yourself, you can follow the information on this site.
