How to use CNC steel bar bending machine

The most significant advantage of energy-efficient or green buildings lies in their ability to conserve resources and energy, protect the environment, and align with the sustainable development of both the economy and society while fulfilling public expectations. Beyond its single-use forming hook functionality, this machine can also serve as a high-performance straightening and cutting machine with a straightening and cutting speed of up to 50 meters per minute. A hook bending machine can support three regular machines (one straightening and cutting machine and two hoop bending machines), reducing labor costs significantly—each machine purchased can save two workers, resulting in clear economic benefits. This robot is designed for ease of use; even someone without prior mechanical knowledge can learn to operate it within 10 minutes. The original reinforcement worker can perform even better with this machine. Its simple design ensures a low failure rate, making maintenance convenient and cost-effective. As we embrace the era of technological advancement and CNC hooks, the product becomes highly automated, boasting fast traction speeds, high work efficiency, and excellent straightening results. Equipped with a touch-screen PLC programmable controller, it only requires inputting the product dimensions to start production. Several notable benefits include: 1. Saving materials by machining steel bars into smaller pieces, avoiding wastage from cutting at the construction site. 2. High operational efficiency with a plate reinforcement machine. A typical 3-4 person team can straighten 7-10 tons of steel bars daily. For stirrup production, a hoop bending machine can produce between 12,000 to 20,000 stirrups a day, and reinforced and horizontal reinforcements can be produced at 7-10 tons daily. 3. Precise ingredient details, such as slab ingredients prepared according to each floor's slabs, making it easier for workers to tie them. 4. Higher production standards, ensuring stirrups, reinforcements, and horizontal reinforcements meet strict quality standards, minimizing errors and saving time for workers. The rebar plate bar machine specializes in processing negative reinforcement for plate bars and small material equipment. Key components: 1. Straightening section: Consists of 19 straightening rollers driven by a motor triangle pulley transmission system and a reducer. The straightening roller includes 14 upper and lower rollers and five horizontal rollers. The down pressure of the movable straightening roller is adjusted to achieve steel bar straightening. 2. Hydraulic shear section: The hydraulic shear section is powered by a 4kw motor driving the hydraulic pump, solenoid valve, and relief valve to control the oil cylinder cutting. The cutting device is installed at the front of the bent hoop section. When working, the stroke switch of the bent hoop part signals the simultaneous cutting and bending of hoops. 3. Electrical control device: Mainly composed of a straightening motor, a bent clamp motor, a hydraulic system motor, a solenoid valve, a console, a length control stroke switch, and a circuit. Power supply specifications: Three-phase AC, 50Hz, 380V; Control power supply voltage: 220V; Straightening motor: 5.5kw; Bent clamp motor: 5.5kw; Shearing motor: 4kw. 4. Automatic bend clamp device: The bend clamp machine completes the bend clamp action through five dials driving five bend points. During operation, the length stroke switch sends a signal to the bend clamp motor, which then drives the dial to execute each bend clamp action in sequence. The steel bar straightening and cutting machine is used for straightening steel bars. With the advent of cold-rolled ribbed steel bars and third-grade steel bars, the use of light round steel bars in construction is decreasing. Thus, the primary focus of this machine is on threading steel bars. Common diameters for building-threaded steel bars are φ8mm, φ10mm, φ12mm, and φ14mm. Our factory’s steel bar straightening and cutting machine minimizes steel bar loss, ensuring no damage, scratching, or twisting occurs. It guarantees a straightening speed of up to 180m/min, producing smooth and straightened steel bars. In summary, this machine not only improves efficiency but also reduces resource wastage, aligning perfectly with modern construction needs.

Galv Cross Arm Cable Support Bracket

Product Name:Galv cross arm cable support bracket

Key words:Galv cross arm cable angle support bracket,Power cross arm cable support bracket,Cross arm cable support bracket for galv

Used to support angle for conner construction

Size:174x12x8

Part No.: Q.Q.Q.000020

Material elongation:20#

Finished: Galvanized,HDG,Plain,Painting,Dacromet,Electrogalvanizing,Oiled,Phosphorization,etc

Place of origina:China

HS Code:730820

Trademark:ZBRF

Color:Customized

Part:Power,Galv

Transport Package:Plastic Bag or Gunny bag and Wooden Case

Port of shipment:Shanghai Port,Taicang Port

Certification:CE,SGS,A.S
